RTL8152B-VB-CG原装以太网芯片
INTEGRATED 10/100M ETHERNET CONTROLLER FOR USB APPLICATIONS
RTL8152B-VB-CG原装以太网芯片 的技术参数：
制造商 | REALTECK |
RoHS | 是 |
类别 | 以太网芯片 |
支持 | USB 2.0 and 1.1 |
封装 / 箱体 | 24-pin QFN ‘Green’ |
类型 | Ethernet Controllers |
标准 | IEEE 802.3, USB 2.0, USB 1.1 |
接口类型 | MII, SPI, USB |
电源电压 | 1V ~ 5.25V |
电源电流 | 60mA |
用途 | 桌面、移动、工作站、服务器、通信平台,对接站和嵌入式应用程序 |
安装类型 | 表面贴装 |
RTL8152B-VB-CG原装以太网芯片 的描述：
The Realtek RTL8152B-VB-CG 10/100M Ethernet controller combines an IEEE 802.3u compliant Media Access Controller (MAC), USB bus controller, and embedded memory.
A linear regulator (LDO) is incorporated for reduced BOM cost. With state-of-the-art DSP technology and mixed-mode signal technology, the RTL8152B-VB offers high-speed transmission over CAT 5 UTP cable or CAT 3 UTP (10Mbps only) cable.
Functions such as Crossover Detection and Auto-Correction, polarity correction, adaptive equalization, cross-talk cancellation, echo cancellation, timing recovery, and error correction are implemented to provide robust transmission and reception capabilities.
The RTL8152B-VB features embedded One-Time-Programmable (OTP) memory. Advanced Configuration Power management Interface (ACPI)—power management for modern operating systems that are capable of Operating System-directed Power Management (OSPM)—is supported to achieve the most efficient power management possible.
In addition to the ACPI feature, remote wake-up (including AMD Magic Packet and Microsoft Wake-Up Frame) is supported in both ACPI and APM (Advanced Power Management) environments.
The RTL8152B-VB supports Microsoft Wake Packet Detection (WPD) to provide Wake-Up Frame information to the OS, e.g., PatternID, OriginalPacketSize, SavedPacketSize, SavedPacketOffset, etc. WPD helps prevent unwanted/unauthorized wake-up of a sleeping computer.
RTL8152B-VB-CG原装以太网芯片 的应用：
USB 10/100M Ethernet on Motherboard, Dongle, Notebook, Docking station, or Embedded system.
