RTL8201FR-VB-CG原装 以太网芯片
SINGLE-CHIP/PORT 10/100M ETHERNET PHYCEIVER WITH AUTO MDIX
RTL8201FR-VB-CG原装 以太网芯片 的技术参数：
制造商 | REALTEK |
类别 | 联网多媒体ICs |
产品类型 | Single-port PHYceiver |
应用程序 | DTV，MCU，CNR |
应用程序 | 打印机，游戏机 |
封装 / 箱体 | 24-pin RMII QFN Green |
低电源 | 1.05V and 3.3V |
RoHS | 是 |
封装 / 箱体 | 24-pin RMII QFN Green |
支持 | IEEE 802.3az-2010 (EEE) |
支持 | Auto-Negotiation |
支持 | Wake-On-LAN (WOL) |
RTL8201FR-VB-CG原装 以太网芯片 的描述：
The RTL8201FR-VB-CG is a single-chip/single-port 10/100Mbps Ethernet PHYceiver that supports RMII (Reduced Media Independent Interface).
The RTL8201FR-VB-CG implements all 10/100M Ethernet Physical-layer functions including the Physical Coding Sublayer (PCS), Physical Medium Attachment (PMA), Twisted Pair Physical Medium Dependent Sublayer (TP-PMD), 10Base-TX Encoder/Decoder, and Twisted-Pair Media Access Unit (TPMAU). The RTL8201FR-VB-CG also supports auto MDIX.
A PECL (Pseudo Emitter Coupled Logic) interface is supported to connect with an external 100Base-FX fiber optical transceiver. The chip utilizes an advanced CMOS process to meet low voltage and low power requirements. With on-chip DSP (Digital Signal Processing) technology, the chip provides excellent performance under all operating conditions.
RTL8201FR-VB-CG原装 以太网芯片 的特征：
Supports IEEE 802.3az-2010 (EEE)
100Base-TX IEEE 802.3u compatible
10Base-T IEEE 802.3 compatible
Supports RMII mode
Full/half duplex operation
Twisted pair or fiber mode output
Supports Auto-Negotiation
Supports power down mode
Supports Link Down Power Saving
Supports Base Line Wander (BLW) compensation
Supports auto MDIX
Supports Interrupt function
Supports Wake-On-LAN (WOL)
Adaptive Equalization
Automatic Polarity Correction
Two network status LEDs
Supports 25MHz external crystal or OSC
Supports 50MHz external Clock input
Provides 50MHz clock source for MAC
Low power supply 1.05V and 3.3V; 1.05V is generated by an internal regulator
11μm CMOS process
24-pin RMII QFN Green package
