MX25V8035FM2I 原装 NOR FLASH
MX25V8035F 2.3V-3.6V, 8M-BIT [x 1/x 2/x 4] CMOS MXSMIO? (SERIAL MULTI I/O) FLASH MEMORY
MX25V8035FM2I 原装 NOR FLASH 的技术参数
类别 | 有源 |
产品族 | 集成电路（IC） |
系列 | 存储器 |
存储器类型 | 非易失 |
存储器格式 | 闪存 |
存储容量 | 8Mb （1M x 8） |
存储器接口 | SPI |
时钟频率 | 104MHz |
写周期时间 - 字，页 | 100μs，4ms |
电压 - 电源 | 2.3V ~ 3.6V |
工作温度 | -40°C ~ 85°C（TA） |
安装类型 | 表面贴装型 |
封装/外壳 | 8-SOIC（0.209"，5.30mm 宽） |
MX25V8035FM2I 原装 NOR FLASH 的特性
2.3V-3.6V for Read, Erase and Program Operations
Unique ID and Secure OTP Support
Multi I/O Support - Single I/O, Dual I/O and Quad I/O
Program Suspend/Resume & Erase Suspend/Resume
MX25V8035FM2I 原装 NOR FLASH 的描述：
MX25V8035F is 8Mb bits Serial NOR Flash memory, which is configured as 1,048,576 x 8 internally. When it is in four I/O mode, the structure becomes 2,097,152 bits x 4 or 4,194,304 bits x 2. MX25V8035F features a serial peripheral interface and software protocol allowing operation on a simple 3-wire bus while it is in single I/O mode.
The three bus signals are a clock input (SCLK), a serial data input (SI), and a serial data output (SO). Serial access to the device is enabled by CS# input. When it is in two I/O read mode, the SI pin and SO pin become SIO0 pin and SIO1 pin for address/dummy bits input and data output.
